1 142500963 前支脚盘 Support Plate Assembly
2 805000106 螺栓 M20×60 Bolt M20×60
3 805300023 垫圈 20 Washer20
4 803002560 前垂直油缸 Front Strut Cylinder
5 143100012 前支腿Ⅰ Front Sliding Beam 1
6 143100042 后支腿Ⅰ Back Sliding Beam 1
7 142501141 盘 Cover
8 142700203 套Ⅰ Sleeve Ⅰ
9 142700199 轴Ⅰ SpindleⅠ
10 137100940 托缸轮 Support Roller
11 805400039 挡圈 20 Washer20
12 142501186 挡块 Block
13 805100039 螺钉 M12×30 Bolt M12×30
14 805300014 垫圈 10 Washer10
15 142501230 滑块 Slider
16 142501241 圆板 Board
17 142500976 板 Board
18 805200116 螺母 M16 Nut M16
19 805000503 螺栓 M17×70 Bolt M17×70
20 144500961 滑块 Slider
21 805200217 螺母 M42×3 Nut M42×3
22 143100028 前支腿Ⅱ Front Sliding Beam Ⅱ
23 143100042 后支腿Ⅱ Back Sliding Beam Ⅱ
24 142501231 滑块 Slider
25 138701072 圆板 Board
26 144500954 套 Spindle
27 805000014 螺栓 M12×45 Bolt M12×45
28 805300018 垫圈 12 Washer12
29 805300020 垫圈 12 Washer12
30 803002557 水平油缸 Level Cylinder
31 137100954 定位销 Anchor Pin
32 136200185 销 Spindle
33 805100047 螺钉 M12×40 Bolt M12×40
34 142100899 绳挡 Block
35 142100883 轴 Spindle
36 142101122 滑轮 Chain Wheel
37 805300118 垫圈 30 Washer30
38 805400002 挡圈 30 Washer30
39 142700196 锁销 Pin Spindle
40 805600182 销 B30×160 Spindle B30×160
41 142100865 支架 Plank
42 805600011 销 6.3×50 Spindle6.3×50
43 142700190 绳排总成 Rigging
44 800500119 轴承 30 Axletree30
45 142700200 支架 Plank
46 805000048 螺栓 M12×35 Bolt M12×35
47 805200069 螺母 M12 Nut M12
48 803002561 后垂直油缸 Back Strut Cylinder
1 805100118 螺钉 M8×40 Screw M8×40
2 142200015 垫块 Pad
3 142701730 吊臂支架 Support
4 805300098 垫圈 20 Washer20
5 805000367 螺栓 M20×2×50 Bolt M20×2×50
1 142701359 左后走台板 Left- Back Covering Plate
2 143100326 左中走台板Ⅰ Left-Middle Covering Plate I
3 142701363 左中走台板Ⅱ Left-Middle Covering Plate II
4 143100570 左中走台板Ⅲ Left-Middle Covering Plate III
5 143100572 左前走台板 Left-Front Covering Plate
6 142700019 围沿 Decorative Stripe
7 142700020 左前围板 Left-Front Coaming
8 142700023 盖板 Cover Plate
9 142700024 立柱 Support
10 142700026 左中围板 Left-Middle Coaming
11 142700029 弯板 Curving Plate
12 142700030 左后围板 Left-Back Coaming
13 142700032 橡胶板 Rubber Plate
14 142700033 橡胶板 Rubber Plate
15 142700034 围沿 Decorative Stripe
16 142700035 围沿 Decorative Stripe
17 142700036 支架 Support
18 142700038 弯板Ⅰ Curving Plate I
19 142700039 弯板Ⅱ Curving Plate II
20 142701358 左后走台板 Left -Back Covering Plate
21 143100327 右中走台板Ⅰ Right-Middle Covering Plate I
22 142701360 右中走台板Ⅰ Right-Middle Covering Plate I
23 142701408 左中走台板Ⅲ Left -Middle Covering Plate III
24 143100571 右前走台板 Right-Front Covering Plate
25 142700046 右前围板 Right-Front Coaming
26 142700048 立柱 Support
27 142700050 右中围板 Right-Middle Coaming
28 142700052 右后围板 Right-Back Coaming
29 142700055 围沿 Decorative Stripe
30 142700056 围沿 Decorative Stripe
31 143100569 围沿 Decorative Stripe
32 142700058 橡胶板 Rubber Plate
33 142700059 橡胶板 Rubber Plate
34 142700060 弯板Ⅲ Curving Plate III
35 142700061 弯板Ⅳ Curving Plate IV
36 142700062 槽钢 Channel Steel
37 143100003 槽钢 Channel Steel
38 142700064 槽钢 Channel Steel
39 142700065 槽钢 Channel Steel
40 143100575 槽钢 Channel Steel
41 142700067 槽钢 Channel Steel
42 142700068 槽钢 Channel Steel
43 142700069 盖板 Cover Plate
44 143100005 上盖板 Cover Plate
45 143100006 盖板 Cover Plate
46 142700072 槽钢 Channel Steel
47 143100679 盖板组件 Cover Plate
48 143100009 盖板 Cover Plate
49 142700077 弯板 Curving Plate
50 142700078 挡板 Cover Board
51 143100576 弯板 Curving Plate
52 138900047 左前包角 Left-Front Wrap Angle
53 138900053 堵板 Cover Plate
54 138901211 盖板 Cover Plate
55 142701216 围沿 Decorative Stripe
56 138900533 尼龙螺栓 Nylon Bolt
57 142501154 装饰角 Decorative Angle
58 138900836 螺栓 Bolt
59 138900069 弯板 Curving Plate
60 144600874 工作灯罩 Headlight
61 138900541 围沿 Decorative Stripe
62 138900078 右包角 Right Wrap Angle
63 142701217 弯板 Curving Plate
64 138900088 支架 Support
65 138500614 前牵引装置 Front Draught Attachment
66 138900566 围板Ⅰ Coaming I
67 138900567 围板Ⅱ Coaming II
68 139100102 托板 Support
69 142200090 板 Plate
70 142200091 踏板 Pedal
71 142500200 配重定位块 Set Counterweight
72 143501194 盖板 Cover Plate
73 144501182 前装饰角 Front Decorative Angle
74 144501183 前装饰角 Front Decorative Angle
75 143100004 槽钢 Channel Steel
76 142700081 右工具箱 Right Tool Box
77 142701194 左前围板 Left-Front Coaming
78 142701195 右侧围板 Right Coaming
79 142701196 围板 Coaming
80 805005717 螺栓 M6×25 Bolt M6×25
81 805203120 螺母 M6 Nut M6
82 805004521 螺栓 M8×20 Bolt M8×25
83 860118482 螺栓 M6×15 Bolt M6×15
84 805004522 螺栓 M8×25 Bolt M8×25
85 805203121 螺母 M8 Nut M8
86 143100412 后防护 Latter Protection
87 805300069 垫圈 8 Washer 8
88 805004535 螺栓 M10×30 Bolt M10×30
89 805201542 螺母 M10 Nut M10
90 144501864 板 Plate
91 805300017 垫圈 10 Washer 10
92 805100154 螺钉 M8×30 Bolt M8×30
93 805047720 螺栓 M16×45 Bolt M16×45
94 142201208 控制箱 Control Box
95 801540441 把手 Handle
96 805047721 螺栓 M16×45 Bolt M16×45
97 143100573 弯板 Curving Plate
98 142701264 盖板 Cover Plate
99 805100077 螺钉 M6×25 Bolt M6×25
100 142700080 左工具箱 Left Tool Box
101 142701104 支架 Support 1
102 142701105 支架 Support 1
103 142701106 扶手 Handle 2
104 142701098 梯子 Ladder 1
105 805004582 螺栓 M14×50 Bolt M14×50 4 GB/T16674.1-2004
106 805203123 螺母 M14 Nut M14 4 GB/T6187.1-2000
107 142701109 围沿 Decorative Stripe 1
108 805100461 螺钉 M6×16 Bolt M6×16 2 GB/T819.1-2000
109 143100578 槽钢 Channel Steel 2
110 805300117 垫圈 8 Washer 8 105 GB/T96.1-2002
111 142701114 支架 Support 2
112 805004525 螺栓 M8×40 Bolt M8×40 24 GB/T16674.1-2004
113 143100590 支架 Support 1
114 805004518 螺栓 M6×20 Bolt M6×20 16 GB/T16674.1-2004
115 805004573 螺栓 M6×10 Bolt M6×10 6 GB/T16674.1-2004
116 805046724 螺栓 M10×25(达克罗) Bolt M10×25 9 GB/T16674.1-2004
117 805238388 螺母 M10(达克罗) Nut M10 9 GB/T6187.1-2000
