1 381600390 固定环 Fixed Ring
2 805048199 螺栓 M12X140 Bolt
3 381600397 铜套 Copper Sheathing
4 380903657 下摆架 DOWN SWING FRAME
5 380903659 叉子 FORK
6 805639021 销 B6×28 Pin B6×28
7 381600392 盖 Cover
8 805338261 垫圈 12 Washer
9 805139877 螺钉 M12×40 Screw
10 381600393 衬套 Bushing
11 381600391 盖 Cover
12 801103215 油杯 M10X1 Oil Cup M10X1
13 805338260 垫圈 10 WASHER
14 805046524 螺栓 M10×16 Bolt
15 805005958 螺栓 M24X100 Bolt
16 805338233 垫圈 24 Washer
17 380901102 上摆架 Up Swing Frame
18 381600396 衬套 Bushing
19 805634937 圆柱销 A12×32 PIN
20 381601144 垫片 washer
21
381601225
伸缩销轴
TELESCOPIC PIN
22 380300928 盖板 COVER
23 805200098 螺母 M12 NUT M12
24 805338276 垫圈 8 WASHER
25 805338259 垫圈 8 WASHER
26 805046503 螺栓 M8X16 Blot
27 805046416 螺栓 M10×30 BOLT
1 380905153 前机架 FRAME
2 805338259 垫圈 8 WASHER
3 805046507 螺栓 M8×20 BOLT
4 380501044 左前灯架 LEFT FRONT LAMPPOST
5 380900841 盖板Ⅰ COVER PLATE
6 805046503 螺栓 M8×16 BOLT
7 380900842 盖板Ⅱ COVER PLATE
8 380901157 弹簧销 Pin
9 380901156 插销 Pin
10 380900916 拉杆 LEVER
11 805046473 螺栓 M10×30 BLOT
12 805338260 垫圈 10 WASHER
13 380901049 梯架 ladder
14 380501083 驾驶室底座 CAB BASE
15 805238374 螺母 M16 NUT
16 380600626 大垫圈 WASHER
17 805046664 螺栓 M16X70 Bolt
18 805338263 垫圈 16 Washer
19 805140490 螺钉M20X50 Bolt
20 805048207 螺栓M16X95 Bolt
21
805338284
垫圈16
Washer
22 380200687 减震装置 Absorber
23 805338261 垫圈12 Washer
24 805046482 螺栓M12X30 Bolt
25 380300672 垫圈 Washer
26 380901046 支板 bracket
27 380901151 压板 Cover Plate
28 805140922 螺钉M6X18 Bolt
29 380901158 橡胶垫 Rubber
30 380902077 右电瓶箱 Right accumulator box
31 805140945 螺钉M6X25 Bolt
32 380901148 橡胶垫 Rubber
33 380501196 后机架 Back Frame
34 380902076 左电瓶箱 Left accumulator box
35 380900922 压板 Cover Plate
36 380900923 上铰轴 Upper Beryllium Axle
37 380900920 压盖 Cover Plate
38 380900921 毡圈 Felt Ring
39 800515283 GE90ES Joint Bearing
40 860101074 挡圈130 Bolt
41 380905146 下铰轴 Ante Beryllium Axle
42 380901044 下压盖 Ante Gland
43 380900915 毡圈 Felt Ring
44 800515288 GEG90ES Joint Bearing
45 805009805 螺栓M12X1.5X40 Bolt
46 380905148 盖板 Cover Plate
47 380905147 螺母 Nut
48 805600080 开口销8X80 Pin
49 805048257 螺栓M20X1.5X45 Bolt
50 380900925 法兰盘 Flange
51 380905149 轴套 Axle Bushing
52 380900918 压板 Cover Plate
53 805046485 螺栓M12X25 Bolt
54 805604514 销轴 Bolt
55 801100336 油杯 M10X1 Grease Nipple
56 805338258 垫圈6 Washer
57 805046496 螺栓M6X20 Bolt
58 380901126 压板I Cover Plate I
59 380901050 橡胶管 Cover Plate
60 380900860 压板II Cover Plate II
61 380900861 衬套 Bush
62 380300684 橡胶带 Rubber
63
380501084
橡胶底板
Rubber
64 380501046 右前灯架 RIGHT FRONT
LAMPPOST
65 380902430 工具箱 Toolbox
65 380600627 大垫圈 Washer
66 380100333 橡胶垫 Rubber
67 805046505 螺栓M8X18 Bolt
68 805338258 垫圈6 Washer
69 805338264 垫圈6 Washer
70 380901147 橡胶带 Rubber
71 805338278 垫圈10 Washer
72 380300682 垫片 Washer
73 805046529 螺栓M10X40 Bolt
74 380300683 横踏板 Paddle
75 805300023 垫圈20 Washer
76 805338265 垫圈8 Washer
77 380501113 橡胶垫 Rubber
78 380501090 橡胶垫 Rubber
79 805338284 垫圈16 Washer
80 805004814 螺栓 M16×55 Bolt
81 380501089 橡胶垫 Rubber
82 380501088 减震垫 Absorber
83
380501088
减震垫
Absorber
84 380501085 前支撑 Support
85 380501086 减震垫 Absorber
86 380501087 平垫 Washer
87 805047561 螺栓 M16×110 Bolt
88 380501111 橡胶垫 Rubber
1 805101783 螺钉 M12×30 SCREW
2 805300018 垫圈 12 WASHER 12
3 805000311 螺栓 M20×55(10.9) BOLT
4 805300023 垫圈 20 WASHER
5 380905027 端盖 COVER
6 380900932 环片 RING PIECE
7 380900935 调整片 ADJUSTING SHIM
8 800515213 圆锥滚子轴承 32018 CONICAL ROLLER BEARING
9 380903073 左倾斜关节 LEFT INCLINED JOINT
10 380901054 前轮辋螺母 NUT
11 801103672 油杯 M10×1 OIL CUP
12 380901130 轮毂 HUB
13 380900931 隔圈 SPACING RING
14 380905026 左转向节 LEFT STEERING
KNUCKLE
15 805140967 螺钉 M16×40(33H) SCREW
16 805200109 螺母 M16 NUT
17 380903067 前桥体 AXLE FRONT
18 800515286 关节轴承 GAC40S JOINT BEARING
19 805604517 销轴 PIN SHAFT
20 805300118 垫圈 30 WASHER
21 805203801 开槽螺母 M30X2 SHOTTED NUT
22 805601535 开口销 6X60 COTTER PIN
23 805203871 螺母 M36×2 NUT
24 380901059 垫片 WASHER
25 380901058 垫圈 WASHER
26 380901055 套 SLEEVE
27 805203197 螺母 M10 NUT
28 805140956 螺钉 M10×90 SCREW
29 805604516 销轴 PIN SHAFT
30 380903077 拉杆 CROSSED ROD
31 380900929 套 SLEEVE
32 380901051 垫片 WASHER
33 805604519 销轴 PIN SHAFT
34 380903080 挡板 JAM RING
35 800515216 滚针轴承 NK55/25 NEEDLE BEARING
36 380900928 钢丝挡圈 RETAINER RING,WIRE
37 380903079 转向销 KING PIN
38 380901064 止推片 THRUST WASHER
39 800515215 推力滚针轴承 THRUST NEEDLE
BEARING
40 380905025 右转向节 RIGHT STEERING
KNUCKLE
41 801103215 油杯 M10×1(不锈钢) OIL CUP M10×1(STAINLESS STEEL)
42 380903069 右倾斜关节 RIGHT INCLINED JOINT
43 805338245 NL-垫圈 20 WASHER
44 805000599 螺栓 M20X50 BOLT
45 805604518 销轴 PIN SHAFT
46 805011330 螺栓 M10×25 BOLT
47 805604683 销 6X80 COTTER PIN
48 380901056 锁紧片 LOCK PLATE
49 805048384 螺栓 M10×75(10.9) BOLT
50 380901101 右球铰 RIGHT BALL JOINT
51 380901069 夹紧环 CLAMP RING
52 805302535 垫圈 10 WASHER 10
53 805300014 垫圈 10 WASHER 10
54 380903062 拉杆 LEVER
55 380903063 连接环 COUPLING RING
56 380904727 连接座 SEAT
57 805048208 螺栓 M16×85(10.9)
58 805203851 锁紧螺母 M16 NUT
59 805338246 NORD-LOCK 垫圈
16 NORD-LOCK WASHER 16
60 380901068 左球铰 LEFT BALL JOINT
61 380901071 垫片 WASHER
62 380902714 前轮辋螺栓 BOLT
63
805000184
螺栓 M10×120
BOLT
64 380901129 垫片 WASHER
65 380901128 油缸支座 BRACKET
66 805100453 螺钉 M16X70 BOLT
67 801702945 碟弹簧 16 DISK SPRING
68 805604515 销轴 PIN SHSFT
69 380901052 止推片 THRUST WASHER
70 805002022 螺栓 M6×18 BOLT
71 805300030 垫圈 6 WASHER
72 805300029 垫圈 6 WASHER
73 380902080 端盖 COVER
74 380300763 垫片 WASHER
